Load interface and mounting stack
Model 31 threads and body dimensions change with range. Include termination and any balance or calibration-memory module when defining the replacement.
MT-ILC-MM / REVISION-SPECIFIC COMPARISON
Honeywell Model 31, Interface WMC & HBK U9C alternatives
These three original families belong in an axial stud-interface review, but their dimensions and measurement chains differ. Keep the original order code, output version and calibration record together.
Direct application engineeringinquiry@inlineloadcell.com ↗Send both interfaces, capacity and output. Your email opens with an engineering checklist.
ORIGINAL MANUFACTURER REFERENCE
Identify the original part before choosing the replacement.
The dimensions and capacities below describe the cited original documents. The proposed MT-ILC drawing, electrical map and calibration scope are supplied for a separate approval.
| Original model / part | Original capacity & interface | Original envelope | Next engineering step |
|---|---|---|---|
| Honeywell Model 31Model 31 / AL311 | Capacity-specific original variantExternal attachments; range-dependent threads | Match range, body height and terminationOriginal document ↗ | MT-ILC-MM reviewCompare this original series →Request this comparison ↗ |
| Interface WMCWMC | Use full original order codeExternal ends; US or metric variant | Capacity-dependent, WMC drawing v2.8Original document ↗ | MT-ILC-MM reviewCompare this original series →Request this comparison ↗ |
| HBM / HBK U9CU9C | Use full original order codeExternal threads; raw or conditioned variants | Match body, thread and amplifier variantOriginal document ↗ | MT-ILC-MM reviewCompare this original series →Request this comparison ↗ |
Termination, clearance and variant
Interface WMC has US and metric variants and capacity-dependent geometry. Copy the complete code and original dimensional row into the mechanical comparison.
Range, protection and system behavior
HBK U9C raw bridge, analog-conditioned and IO-Link variants are different electrical interfaces. A four-wire mV/V wiring map cannot be reused for an IO-Link or powered transmitter.
BRIDGE / CONDITIONER / CONTROLLER
Match the signal chain as well as the thread.
Review whether the existing PLC reads a raw bridge, analog engineering units or a digital protocol. Match power, pinout, polarity, scaling, filter/update delay and the commissioning zero/span procedure.
Review a paired conditioning kit →Ask for a drawing-led comparison record.
- Original order code, drawing revision and calibration record.
- Proposed MT-ILC interfaces, envelope and cable/connector definition.
- Side-by-side excitation, sensitivity, polarity, units and output scaling.
- Calibration points, serial association, prototype quantity and quoted lead time.
Original-brand prices and delivery dates change by item and configuration. Request a current quote; no universal saving or interchangeability percentage is assumed.
Resolve the fit, signal and calibration questions.
Can all three brands use the same replacement pinout?
No. Obtain the wiring and output definition for the exact original version, then specify the proposed cable or connector pin-by-pin.
Will an existing calibration certificate remain valid after a change?
A replacement changes the measurement chain. Request a serial-linked calibration scope for the supplied sensor and conditioner, and define the system acceptance check.
ENGINEERING RFQ / SAMPLE REQUEST
Send the load case.
Define the interfaces.
Include both thread ends, working and peak force, available space and the signal your controller expects.
Company and university email domains are preferred. Prototype and research inquiries are welcome.
inquiry@inlineloadcell.com ↗
